3M 79

3M 79 is a printable tape used in coils/transformers and motor applications. It includes an outer wrap for bobbin wound coils, banding arbor wound coils, lead pad hold downs, end turns and lead anchors, as well as connections. This tape is 600V rated and withstands a temperature range of 32 to 302 °F (0 to 150 °C).

  • Color: White
  • Backing: Glass Cloth
  • Thickness: 7 mil | 0.178 mm
  • Adhesive: Acrylic

3M 79 has a pressure-sensitive, acrylic adhesive that offers optimized adherence and resists edge tears. This conformable tape is solvent resistant and has a glass cloth backing that will not shrink, burn or rot while ensuring maximum stability. The printable tape is designed for banding and strapping applications. It provides excellent absorption of varnishes and resin. UL Listed and RoHS 2011/65/EU Compliant.

  • Pressure-sensitive, acrylic adhesive offers optimized adherence
  • Glass cloth backing ensures maximum stability
  • Designed for coils/transformers and motor applications
  • Printable and has the ability to absorb resin and varnishes
  • Withstands a temperature range of 32 to 302 °F (0 to 150 °C)
  • Highly conformable and resists solvents
  • UL Listed and RoHS 2011/65/EU Compliant
3M 79
3M 79
3M 79
3M 79

3M 79 Features

  • High-temperature resistance (150 °C)
  • Excellent Conformability
  • Superb absorption of resin and varnishes
  • Printable
  • High solvent resistance

3M 79 Applications

  • This tape is suggested for use in a variety of coil/transformer and motor applications including an outer wrap for bobbin wound coils, banding arbor wound coils, lead pad hold down, end turn, and lead anchor and connection.
